1325 High Quality Oscillating Knife Cnc Router For Leather

Name: 1325 High Quality Oscillating Knife Cnc Router For Leather
Brand: UTECH
SKU: 46572342
Rating: 5.0 (44 reviews)

1325 UTECH Sofia Series Hot Sale China Oscillating Knife Cnc Router carving machine 3d cnc router machine 1325 price

Control System Brand:	NC Studio, Siemens, Syntec, Mach3, DSP, RichAuto
Range of Spindle Speed(r.p.m):	1 - 24000 rpm
Spindle Motor Power(kW):	5.5KW
Availability:



Inquire Add to Basket

Model:
Sofia
Brand:
UTECH
Code:
UT-1325

Sofia series OKC cnc router

Description:

1. The bed is made of high-rigidity rectangular steel pipe welded and optimized dragnet structure, aging treatment to ensure the precision of the bed.
2. Double heads device--spindle and oscillating knife, can be cut according to different materials. After many improved tests, we update machine, now machine only have one Z axis for spindle and oscillating knife, it’s integrated together to share one z-axis motor&drive, and doesn’t need another set of motor&driver to control the z-axis of oscillating knife separately.
3. Excellent visual positioning system, one-click cutout and one-click start processing, free of typesetting&cutout time, improve processing efficiency. Equipped with professional 1.5 megapixel industrial camera, powerful image recognition, more accurate cutting.
4. Oscillating knife head can be processed and tracing-edge cutting according to different materials, the material dust-free and without raw edge.
5. CCD: Tracing-edge cutting for different materials, KT board, PVC, photo paper to achieve no burr cutting.
6. Transmission model adopt precision reducer match with brand gear rack, large torque, low noise and high transmission precision accuracy.
7. Machine supports DXF, JPG, PNG, NC and other formats, not only with automatic tracing-edge, but also support the function of CNC router.

okc海报

Parameters:

working area	13002500200mm
Table structure	Table structure
Spindle motor	4.5kw air cooling spindle
Control system	Utech-knife visual control system
Viual system	CCD camera for tracing-edge
Driver	Leadshine 758 hybrid servo motor&driver
Inverter	5.5kw xinfutai inverter
Oscillating knife	EOT-3 structure
Transmission	XY axis with WMH herion 1.5M Helical rack,three sets of Japan SHIMPO reducer 1:10,Z axis with Taiwan TBI ball screw,XYZ axis by Taiwan PMI 25 rail guide rail

Applications:

EOT-3 - Oscillating Tangential Knife for cutting cardboard, veneer, textile, rubber, felt, leather and much more.

EOT-3 Common cutting applications/materials
l Sealants
l Carbon fiber
l Corrugated cardboard / hardboard
l Leather and cork
l Tissues and films
l Rigid foam panels
l Carpet
l Rubber

Machine with oscillating knife, CCD visual positioning system and cnc spindle. Except EOT-3 oscillating knife for cutting many kinds of soft materials, CCD visual positioning system with automatic tracing-edge, also support the function of CNC router.

atc appilication

1/ EOT-3 - Oscillating Tangential Knife
The EOT-3 is a processing unit for CNC-machines to cut various materials such as cardboard, sealing materials, foils, corrugated cardboard, carbon fiber prepreg material, leather, rigid foam and many others. A powerful oscillation motor moves the blade quickly up and down while an actuator rotates the blade in each direction of cutting. Thus, even strong and thick materials can be cut precisely and quickly.

* CNC-machined, rugged metal housing
* Precision kinematics
* Oscillation frequency: approx. 3500 –7000 stroke per minute (12-20VDC)
* Drive motor with multiple ball bearings
* Opto-electronic, contactless detection of the blade position
* Equipped with a reverse polarity protection and an optical display for the working status
* Internal voltage regulator and stabilizer
* Equipped with a signal amplifier that generates a clearly defined digital signal for the reference position of the tangential
axis.
* High compatibility with equipment from different manufacturers

2/ UTECH-Knife V5.5.0 Visual Positioning Cutting&Engraving Control System
Multifunction controller with PCI card slot, could support oscillating knife, CCD camera and spindle.

3/ CCD camera for tracing-edge
Equipped with professional 1.5 megapixel industrial camera, powerful image recognition, more accurate cutting.

4/ Machine Base Frame
The base frame is fabricated from heavy-duty tubular steel that is welded, precision machined and stress relieved so that the foundation remains true and steady over the operational life of the machine.

5/ Anodized Aluminum Spindle Fixing plate
The spindle is fixed on the high quality aviation aluminum T6061/6063 plate, and it is Anodized Aluminum processing, the plate is machined by high precision CNC machining center.

6/ Dust cover for the guide rail and the helical rack gear
The machine is designed with the dust cover for the guide rail and the helical rack and gear, to reduce friction, make the rail and the rack have longer service life.

7/ Japan SHIMPO 1:5/1:10 gear reducer + Servo motor&driver(Delta/YASKAWA/Panasonic)
Due to machine with servo motor&driver, then we install Japan SHIMPO 1:10 gear reducer on driving motor, makes the motor is more powerful, and having a longer time service life.
The servo motors are installed on all axis to ensure precise positioning of the gantry and the spindle in accordance with a
predetermined program at high speed. Hybrid servo or Delta servo motors are well proven high degree of reliability.

8/ Reserved Position for Forklift
Bed welding process increases the reserved forklift, highlights two major advantages: First, increase the strength of the bed itself; Second, it`s more convenient for customers to load or unload the equipment.
