Cnc Router With CCD Vision Router System is among the most versatile CNC machining systems you will find on the market. The T-slot bed makes it very easy to place the sheet stock down for cutting and routing, and even setup custom jigs, fixtures and clamps for parts marking applications.
| Structure: | |
|---|---|
| Cutting Area: | |
| Working Table: | |
| Spindle: | |
| Advantage: | |
S2-1530CCD
UTECH
Multifunction CNC Router with CCD Camera System
Hot Using MDF Wood Door Cabinet Making Woodworking 1325 Router CNC Router Machine
1, Hot Using MDF Wood Door Cabinet Making Woodworking 1325 Router CNC Router Machine adopts heavy-duty bed, square tube welding, side-hanging structure, heavy-duty columns, 150*200mm gantry, to ensure that the equipment overall operational stability.
2.Hot Using MDF Wood Door Cabinet Making Woodworking 1325 Router CNC Router Machine transmission model adopts precision speed reducer matching brand rack and pinion, high torque, low noise, high precision transmission accuracy.
3. Single system control, eliminating the need for a second boot switching system, saving time and effort.
4. For KT board, PVC, photo paper and other different materials to chase the edge cutting, to achieve burr-free cutting.
5.Hot Using MDF Wood Door Cabinet Making Woodworking 1325 Router CNC Router Machine is equipped with professional 1.5 megapixel industrial camera, powerful image recognition ability, cutting more accurate.
6.Hot Using MDF Wood Door Cabinet Making Woodworking 1325 Router CNC Router Machine supports formats such as DXF, JPG, PNG, NC, etc. It not only has the function of automatic edge chasing, but also supports the function of CNC milling machine.
5.5kw Water Cooling Spindle
The High-quality SESAME series CNC Router machine comes with a 5.5kw water-cooled high-frequency spindle. This precision spindle requires no maintenance, uses industry-standard ER25 collects, support cutter size of 3.175, 4, 6, 8, 12.7, 16mm. Fully programmable speeds from 18000 to 24000RPM.
CCD Camera
Based on standard SESAME CNC, added visual positioning function, equipped with a professional 1.5-megapixel industrial camera, powerful image recognition, more accurate cutting. Single system control, eliminating the switching system of the second boot, save time and effort. A set of control systems with spindle engraving cutting and CCD automatic tracing-edge functions.
UTECH Patent Type Reducer
UTECH equipment is equipped with a standard reducer structure---patented step reducer/Japan SHIMPO reducer 1:5/1:10. Compared with the reduction gear and the structure inside the gearbox, the belt of the timing belt has a certain tension and is easy to loosen. It is often necessary to change the belt. There is also a gearbox for the machine to decelerate. When the machine needs to decelerate and stop, the gearbox has no effect. Obviously, and due to the use of timing belts, great inertia is easy to slip and overtravel.
The reducer has the characteristics of low backlash, low noise, high strength, and accurate deceleration effect.
Control System
SESAME CCD uses Multech/Xingduowei controller, controller by computer, you can view the work path visually. Support multiple workpiece coordinate systems, access workpiece coordinate systems. Support line number processing, breakpoint continues, power continues, cycle processing.
Oil Mist Cooling System
Oil mist lubricator is driven by compressed air, sprays oil fog particles in the size between 0.5 and 15. It's applied for lubrication and cooling of lubrication points. It's equipped with an electromagnetic valve. When connected with the main unit electric control, it can realize control of lubrication time. It’s ideal for coolant tools for cutting metal. The result is higher material removal rates, improved finish, tighter tolerances, and increased productivity.
Forklift Location
The bed welding process increases the position forklift, increases the strength of the bed itself, And it’s more convenient for customers to load or unload the equipment.
Dust Cover for Rail Guide and Gear Rack
The machine is designed with the dust cover for the guide rail and the helical rack and gear, to reduce friction, make the rail and the rack have a longer service life.
Lathe Bed
The base frame is fabricated from heavy-duty tubular steel that is welded, precision machined and stress relieved so that the foundation remains true and steady over the operational life of the machine.
Taiwan PMI Rail Guide&High quality helical rack pinion
SESAME choose a heavy-duty linear guide rail with a high assembly Flange sliding block and PMI linear guide. The Y-axis adopts a double-row four-column guide rail, with strong bearing force, fast speed, smooth operation, high precision, and high life span.
Rack of Sesame adopts a high-precision 1.25 helical rack, which is complementary with the professional motor and professional deceleration device, which runs smoothly, high speed, high precision, and low noise.
Applicable Industry
Advertising industry:
Acrylic, two-color plate, PVC, ABS plate, aluminum plate, two-color portrait, three-dimensional advertising, various standard equipment, badges, coordinate plates, brass plates, fonts, typefaces, all kinds of signs, trademarks and so on.
Woodworking industry
Furniture decoration, musical instrument manufacturing, wooden handicrafts, solid wood furniture, office furniture, customized furniture, MDF paint-free doors, composite doors, cabinets, closets, windows and doors, bedside cabinets, etc.
Decoration Industry
Art models, murals, screens, relief sculptures, decorative processing, gift packaging, wave boards, electrical countertops, sporting goods and other wood products.
