UTECH Multifunctional 1325 CCD Edge Cutting CNC Wood Router Engraving Machine uses a 5.5kw water-cooled spindle, which has the characteristics of high speed and low noise. It is also equipped with a CCD visual recognition system with automatic edge finding, positioning and cutting functions. Single system control, no need to start the system twice, has spindle engraving and cutting and CCD automatic tracing functions, easy to operate.
| Structure: | |
|---|---|
| Cutting Area: | |
| Working Table: | |
| Spindle: | |
| Advantage: | |
S2-1530CCD
UTECH
Multifunctional 1325 CCD Edge Cutting CNC Wood Router Engraving Machine
UTECH Multifunctional 1325 CCD Edge Cutting CNC Wood Router Engraving Machine uses a 5.5kw water-cooled spindle, which has the characteristics of high speed and low noise. It is also equipped with a CCD visual recognition system with automatic edge finding, positioning and cutting functions. Single system control, no need to start the system twice, has spindle engraving and cutting and CCD automatic tracing functions, easy to operate. And our machine has a patented detachable structure, which can save you shipping costs. Our machines support customization. Whether it is the working area or accessories selection, the UTECH team can customize it according to the user's requirements.
1300*2500*200mm
5.5kw water cooled spindle+ER25 collect
CCD visual positioning system
Aluminum T-slot table
Stepper motor&driver*4+Reducer structure*3
XY axis by 1.25M helical rack gear transmission, Z axis by Taiwan TBI ball screw
XYZ axis by Taiwan PMI 20 rail guide
Detachable structure (Two/Three sets 1325 SESAME could packed via a wood box)
5.5kw Water Cooling Spindle
The High-quality SESAME series CNC Router machine comes with a 5.5kw water-cooled high-frequency spindle. This precision spindle requires no maintenance, uses industry-standard ER25 collects, support cutter size of 3.175, 4, 6, 8, 12.7, 16mm. Fully programmable speeds from 18000 to 24000RPM.
CCD Camera
Based on standard SESAME CNC, added visual positioning function, equipped with a professional 1.5-megapixel industrial camera, powerful image recognition, more accurate cutting. Single system control, eliminating the switching system of the second boot, save time and effort. A set of control systems with spindle engraving cutting and CCD automatic tracing-edge functions.
UTECH Patent Type Reducer
UTECH equipment is equipped with a standard reducer structure---patented step reducer/Japan SHIMPO reducer 1:5/1:10. Compared with the reduction gear and the structure inside the gearbox, the belt of the timing belt has a certain tension and is easy to loosen. It is often necessary to change the belt. There is also a gearbox for the machine to decelerate. When the machine needs to decelerate and stop, the gearbox has no effect. Obviously, and due to the use of timing belts, great inertia is easy to slip and overtravel.
The reducer has the characteristics of low backlash, low noise, high strength, and accurate deceleration effect.
Control System
SESAME CCD uses Multech/Xingduowei controller, controller by computer, you can view the work path visually. Support multiple workpiece coordinate systems, access workpiece coordinate systems. Support line number processing, breakpoint continues, power continues, cycle processing.
Oil Mist Cooling System
Oil mist lubricator is driven by compressed air, sprays oil fog particles in the size between 0.5 and 15. It's applied for lubrication and cooling of lubrication points. It's equipped with an electromagnetic valve. When connected with the main unit electric control, it can realize control of lubrication time. It’s ideal for coolant tools for cutting metal. The result is higher material removal rates, improved finish, tighter tolerances, and increased productivity.
Forklift Location
The bed welding process increases the position forklift, increases the strength of the bed itself, And it’s more convenient for customers to load or unload the equipment.
Dust Cover for Rail Guide and Gear Rack
The machine is designed with the dust cover for the guide rail and the helical rack and gear, to reduce friction, make the rail and the rack have a longer service life.
Lathe Bed
The base frame is fabricated from heavy-duty tubular steel that is welded, precision machined and stress relieved so that the foundation remains true and steady over the operational life of the machine.
Taiwan PMI Rail Guide&High quality helical rack pinion
SESAME choose a heavy-duty linear guide rail with a high assembly Flange sliding block and PMI linear guide. The Y-axis adopts a double-row four-column guide rail, with strong bearing force, fast speed, smooth operation, high precision, and high life span.
Rack of Sesame adopts a high-precision 1.25 helical rack, which is complementary with the professional motor and professional deceleration device, which runs smoothly, high speed, high precision, and low noise.
SESAME CNC Router's Parameters:
| 1 | Machine Structure | Spindle+CCD Camera (oscillating knife is optional) |
| 2 | Model | UT-1325/UT-1530/UT-1632/UT-2131/UT-2141 |
| 3 | Accuracy | ±0.02mm |
| 4 | Table Surface | Vacuum/T-slot table OR Double table |
| 5 | Frame | Square pipe welding bed structure 200*300mm+150*200mm gantry |
| 6 | X, Y Structure | 1.25M Helical gear rack transmission, Taiwan Linear Rail Guide |
| 7 | Z Structure | Taiwan TBI Ball Screw, Taiwan Linear Rail Guide |
| 8 | Spindle Power | 5.5kw water cooled spindle+ER25 cutter |
| 9 | Spindle Speed | 18000-24000RPM |
| 10 | Drive Motors | JMC stepper motor and driver+UTECH patent typre reducer |
| 11 | Operating System | Xingduowei/Multech controller |
| 12 | Dust Collector | 2.2kw/3kw/5.5kw/7.5kw |
| 13 | Software | Vectric Aspire/Type 3 /Artcam /Ucancam/JDPaint |
