Advantages:
1. Cutting faster, more accurate control, the cutting surface is more smooth, no glitches, no black; cutting holes in high quality
2. Stability and reliability for light path system and control system
3. Humanizing design, convenient operation
4. High-performance price ratio, low operating cost >High cutting efficiency, and quality, no noisy. Small heat influence area, cutting seam smooth and no deformation, post-treatment is not needed
5. The machine adopts Beijing START plasma control system, standard high sensitivity arc voltage device
6. High precision stepper motor and driver, ensure the efficiency and accuracy, increasing the stability and reliability greatly
Configurations:
Standard Configurations:
1) standard working area 1300*2500mm working area
2) Beijing STARFIRE control system 63A+ARF Height Controller(Automatic Rise and Fall)
3) JMC stepper motor&driver
4) Gear rack and square rail guide transmission
5) Sawtooth table
6) Heavy duty machine body with 5mm thick square tube
7) FASTCAM software
8) Instruction of STARFIRE control system and FASTCAM software.
9)Huayuan 120A plasma Power(Optional: Hypertherm power supply)
10)Cutting Material Collection Box with wheels, for easy take out products
Optional parts:
1) Servo motor&driver(any brnad)
2) Huayuan 63A, 100A, 120A, 160A, 200A; Hypertherm 45A, 65A, 85A, 105A, 125A
3) Water tank/Water table 4) Flat table Etc.
