Professional Electric Plasma Cutting Machine For Titanium

Greatly used with steel, Carbon Steel, Stainless steel, alloy steel, spring steel, copper plate, aluminium plate,gold, silver.
Spindle Motor Power:
Control system:
Plasma power:
Cutting thickness:
Worktable:
Availability:
Professional Electric Plasma Cutting Machine For Titanium
Professional Electric Plasma Cutting Machine For Titanium
Professional Electric Plasma Cutting Machine For Titanium
Professional Electric Plasma Cutting Machine For Titanium
Professional Electric Plasma Cutting Machine For Titanium
Professional Electric Plasma Cutting Machine For Titanium
  • Plasma

  • UTECH

  • UT-1325P

UTECH Sesame Series Plasma CNC Router For Metal And Nonmetal

Working area: 1200*1200mm, 1300*2500mm, 1500*3000mm, 2000*4000mm etc.

Plasma power: Huayuan 63A, 100A, 120A, 160A, 200A

                               Hypertherm 45A, 65A, 85A, 105A, 125A

等离子

Machine Description:

CNC plasma cutter is a computer-controlled machine with a cutting table, a plasma generator, and other CNC kits. We also call it CNC plasma table, CNC plasma cutting table, CNC plasma cutting machine, etc. It is the most popular metal cutting machine in this world. Because it can cut almost any metal well in quality, from steel, stainless steel, aluminum, copper, titanium, etc. CNC plasma cutter also has the advantages of fast cutting speed, smooth cut surface, little heat distortion & deformation.

1) Support FASTCAM nesting software such as the standard G code path generated file can also be also can change software to read AUTOCAD softwares produce DXF form documents. U disk exchange control system processing files, easy to operate.

2) The beam uses light structural design,with good rigidity structure, welded lathe bed of thick profiled steel, more solid and stable.
3) Cutting mouth is small, tidy,and avoid a second dressing processing.

4) High cutting speed, high precision, and low cost.


 Features of plasma cutting machine:

♦ working area: 1300*2500mm

♦ Heavy duty thicken machine body

♦ 200A Hypertherm plasma power

♦ Stepper motor and Leadshine Driver

♦ Start Controller system from Beijing

♦ Automatic Arc Pressure adjustable

♦ HIWIN Linear Guide Rail

♦ Helical Rack and Pinion

♦ Fast Cam software

♦ warranty : 1 year


CNC plasma cutting machine advantages:



1. Plasma power

Hypertherm 200A power

Famous brand all of the world, low price, Cutting thickness 0.3-52mm

2. Controller system

Beijing Start control system,

configured 7-inch high-resolution true color LCD display. can be dynamically cut graphics running track.

3. Motor

450B stepper motors

With high quality & stronger power, ensure machine work very well.

4. Driver

Leadshine 860H Drivers

It can run with smaller noise, lower heating, smoother movement and have better performances at higher speed.Save human strength and save time.

5. Automatic Arc Pressure adjustable

Beijing Start

Adjust the torch height during cutting. Perforated height self-positioning

6. software Fast Cam
nesting software for machine. Using it, and finally export G code, then can be recognized by machine


Standard Configurations:



1) 1300*2500mm working area(1530, 2030, 2040, 2060 could be customized)
2) Beijing STARFIRE control system+Arc Height Controller

3) Huayuan 63A power supply (According to your work)
4) JMC stepper motor&driver
5) Gear rack and square rail guide transmission
6) Sawtooth table
7) Heavy duty machine body with 5mm thick square tube
8) FASTCAM software
9) Instruction of STARFIRE control system and FASTCAM software.


Optional parts:

1) Servo motor&driver(any brnad)

2) Huayuan 63A, 100A, 120A, 160A, 200A; Hypertherm 45A, 65A, 85A, 105A, 125A

3) Water tank/Water table

4) Flat table

5) Fangling control system

Etc.



CNC plasma cutting machine applications:

It is widely used in the process of cutting metal plates in the machinery manufacturing industry, engineering industry, and metal fabrication and can cut mild steel, stainless steel, aluminum, copper and many kinds of non-ferrous metal.

Advertising industry:
Advertising signs, logo making, decorative products, production of advertising and avariety of metal materials.
Metal industry:
For steel, Carbon Steel, Stainless steel, alloy steel, spring steel, copper plate, aluminium plate,gold, silver, Titanium and other metal plate and tube.

应用

CNC plasma cutting machine's description:



Model UT-1325P CNC Plasma cutting machine (Other models are optional)
Working size 1300x2500mm (4x8ft)   (Other working sizes are optional)
Three axes repeat positioning accuracy ±0.05mm
Process precision   ±0.35mm
Transmission system

X, Y: Taiwan Hiwin high-precision, zero clearance increased linear guide+ rack

Z: the arc voltage control

Max. cutting speed 15000mm/min
Working voltage      AC220/50HZ
Control system

Starfire plasma cutting system

Standard high sensitivity arc voltage device

Software support FASTCAM,AutoCAD,etc
Instruction format G code
Drive system Stepper motor
Plasma power supply Huayuan 63A/120A/160A/200A. Optional, USA Hypertherm, 45A/65A/85A/105A/125A



PS, Working area, Plasma power, Power supply's brand, Machine color, all could be customized for you.



Some differences between Huayuan and Hypertherm power supply:



Steel Tube Cutter Table 1530 CNC Plasma Cutting Machine Iron/ Stainless Steel/ aluminum/ copper CNC

PS, if you're not sure which kind of plasma power is suitable for you, you can share the following information for me, I'll suggest you choose proper type.

1/ Which kind of metal materials you wanna cut?

2/ How about the cutting thickness?

Package Details:


The machine will be packed with wrapping film, EPE foam, and wooden case(composite material box/plywood case).

SESAME CNC Router's machine legs and machine bed can be separated freely, when machine shipping, we'll dismantle the machine legs, they can help you save more shipping fee.



1. Our Wooden Case is after fumigation treatment. Needn`t timber inspection, saving shipping time.
2. All the spare parts of the machine were covered by some soft materials, mainly using Pearl Wool. Avoiding all damages that could happen in the delivery process. Then we`ll cover plastic wrap out it tightly, make sure intact of the covered soft materials, also avoiding Waterproof and rustproof.
3. The outmost is Wooden Case With Fixed Formwork.
4. The bottom of the wooden case has a firm iron jack, convenient for handling and transport.


Company Information:


"///UTECH" is the new logo brand after the transformation of "Shandong U-May CNC  Technology Co., Ltd.". "/// "aims to record the important strategic transformation of the company from  ordinary business innovation to high-quality operation in the three years after  its establishment; "U" is "U-May"'s homophonic characters; "TECH" means the CNC technology. At the same  time, when the company was founded three years, the establishment of the Ministry  of Foreign Trade, so "///UTECH" became the company's new logo, and the company's  development philosophy "Smarter Solution, Better Tomorrow."


Our Service:


1. Whole machine with one year warranty, within one year, if there has parts broken, you can send back to us, then we'll send a new one to you.
2. Free training course at our plant or on line.
3. After the warranty period, we'll provide the consumable parts at an agency price when you need replacement.
4. 24 hours on line service each day, free technical support.
5. Before machine delivery, we'll install all parts and test machine for you. We'll take machine's working video and machine photos for you for checking, if confirmed there're no problem, then we'll delivery machine. And if dont dismantle the gantry (if working area more than 1325, then need dismantle machine gantry for putting it into container), after machine arrived, you just need connect plasma power supply, software etc, it's more easily for you. If you're worried, we can take a teaching video for you at that time. By the way, during the production of machine, we also can share the process with you.
6. As for training, firstly we'll take more teaching video for you, and we also can remote control, most important, if you need, we can provide our technicians for on-site training and on-site teaching. And if you wanna, welcome to visit us, you can operate and learn your machine by yourself.
7. After machine shipped, I'll prepare some documents, like B/L, Packing List, Commerical Invoice, Commerical Contract, CE certificate for helping you pick up your machine.
