Name: 4*8FT Small CNC Plasma Cutting Machine For Metal And Nonmetal
Brand: UTECH
SKU: 42454945
Rating: 5.0 (15 reviews)

4*8FT Small CNC Plasma Cutting Machine For Metal And Nonmetal

characteristics:

(1) Welded thick-walled steel structure, after special treatment, no distortion for the whole structure high precision, and long service life time.

(2) Cutting system use Beijing Starfire system/ Start system/ FLMC-2300A or DSP system; Equipped with automatic height controller (THC controller), which can according to your material planeness, cutting head can automatically stable, and fast adjust.
(3) Taiwan HIWIN linear rail, ensure vertical section, more precision.
(4) Suitable software: Artcam/ Fastcam/ Starfire etc.
(5) FASTCAM programming software based on AutoCAD automatic programming and material system.
(6) FASTCAM is designed for all kinds of NC cutter with cutting software, the software can help the user completing various complex parts drawing, programming, material, using convenient, also bring the obvious economic benefit.
(7) If you cut thick material, according to actual use, we’ll add water tank for you for free, to absorbs a large amount of smoke generated during cutting.
(8) Machine could be customized, whatever specifications, appearance, etc. Any request you’ve, could tell us directly.

Details:

Model	SESAME P1
Working size	1300mm*2500mm, 100mm stroke z-axis sliding table
Cutting speed	10-15m/min
Transmission system	1.25m rack, square 20 linear guide and slider
Operating System	Starfire SF2100/DSP A12 control system
Driver	JMC stepper motor and driver
Plasma power supply	Huayuan/Hypertherm
Cutting thickness	0-30mm
Cutting type	Plasma/oxy-acetylene or propane
Input voltage	3 phase,220v/380v±10%
Mode of file transfer	USB Interface
Water tank	Underlay stainless steel sink(absorb smoke and prevent burning)
Table-board	sawtooth + square pipe, spacing is 70 mm
Straight line positioning precision	±0.2mm/10m
Straight line repeat precision	±0.3mm/10m
Environmental temperature	-5~45°C
Humidity	<90% No concreting

Features:

1. Welded thick-walled steel structure, after special treatment, no distortion for the whole structure high precision, and long service life time.

2. Cutting system use Beijing Starfire system/ Start system/ FLMC-2300A or DSP system; Equipped with automatic height controller (THC controller), which can according to your material planeness, cutting head can automatically stable, and fast adjust.

3. Taiwan linear rail, ensure vertical section, more precision.

4. Suitable software: Artcam/ Fastcam/ Starfire etc.

5. FASTCAM programming software based on AutoCAD automatic programming and material system.

6. FASTCAM is designed for all kinds of NC cutter with cutting software, the software can help the user completing various complex parts drawing, programming, material, using convenient, also bring the obvious economic benefit.

7. If you cut thick material, according to actual use, we’ll add water tank for you for free, to absorbs a large amount of smoke generated during cutting.

8. Machine could be customized, whatever specifications, appearance, etc. Any request you’ve, could tell us directly.

Plasma cutting head

1/ Including control box for adjusting height, photoelectric switch and limit switch.

2/ Adjust the distance automatically as the different materials.

3/ The sensor can induce the surface automatically.

Starfire control system+THC Arc voltage regulator

1/ Constituent part: Control system: Beijing Starfire control system, Beijing Start controller, DSP controller, FLMC etc.Plasma and Flame head also with different choice, according to your work and request, we'll give you proper suggestions.

2/ Z axis up-down lifting system: Shenzhen HYD.

Gear transmission+Taiwan HIWIN rail guide

XY axis by gear rack transmission, HIWIN rail guide to make machine higher precision, faster cutting speed, more bettre cutting performance.

Plamsa power supply

Here're two hot types power supply, one is Chinese Huayuan power supply, the other is America Hypertherm power supply. You can choose any brand according to your using habit and budget, local place's voltage.

Machine table

Plasma table has two types, one is flat cutting table, the other is sawtooth cutting table. UTECH plasma usually adopt 5mm thick sawtooth table. It also depends on your request, all could be customzied.

Motor&driver

Two types of motor&driver for choosing:

1) Stepper motor&driver

2) Panasonic servo motor&driver Whole machine with three sets motor&driver, brand could be customized.

Split structure

Machine legs and machine body could be splitted freely, then could help you save much space and shipping freight. A 20GP container could accommodate 6 sets machine.

You can choose to disassemble or not disassemble according to your personal needs during transportation. The installation is also very simple. We will provide the installation video for your reference.

Water pipe

Whole machine with a piece water pipe, connect with cutting nozzle.

Fastcam software

FASTCAM is designed for all kinds of NC cutter with cutting software, the software can help the user completing various complex parts drawing, programming, material, using convenient, also bring the obvious economic benefit.

Exhaust fan(optional)

For absorb the smoke from cutting, here're two ways, one is add water table, it could adsorb smoke above the table; the other way is add exhaust fan, it could adsorb smoke under the table.

Shandong U-MAY CNC Technology CO., LTD. Specializes in machinery R&D, development, production. Our "UTECH" brand CNC Router has occupied CNC Router market with absolute advantage. Since the establishment of our company has been committed to professional CNC Router research and development production. We adhere to the "integrity-based, innovative products, effective communication, quality service" for the company's purpose, "technical service customers" based team spirit, and formed a complete set of one-stop service system for design, installation, commissioning, training and maintenance . 1. Independent research and development of High Precision&Speed CNC Cutting Machine.

2. The industry's first electronically controlled fully automated start-stop device.

3. The whole machine thermal aging treatment.

4. High precision T6 aviation aluminium profile machined parts.

5. Humanized design concept.

6. High Engraving processing efficiency, smooth cutting edge, good processing quality.

Working Table Size:	1325(4*8ft)
Motor and driver:	JMC stepper motor and driver
Power Source:	Chinese Huyuan or USA Hyperterm
