SESAME S2
UTECH
4x8 Ft Cnc Wood Carving Machine 1325 Wood Working Cnc Router for Sale
SESAME Series CNC milling machines feature a heavy-duty thickened bed welded with 200*300mm square tubes, side hanging structure, cast iron column and 150*200mm gantry frame. Equipped with CNC machining center to finish precision aviation aluminum head parts.
SESAME series CNC milling machine adopts reducer structure. Compared with the characteristics of loose gear box and synchronous belt, short life and no obvious deceleration effect, SESAME series CNC milling machine has the advantages of small backlash, low noise, high strength and accurate deceleration. Impact.
SESAME series CNC routers are assembled by the precision instruments of the professional assembly team of Youte, ensuring the accuracy of repeated positioning ±0.01mm and the accuracy of returning to the mechanical origin ±0.02mm.
SESAME series CNC routers use industrial-quality, high-precision linear guides to provide less rolling torque resistance and greater motor torque. And with dust cover, reduce friction, prolong service life.
4x8 Ft Cnc Wood Carving Machine 1325 Wood Working Cnc Router for Sale
SESAME Series CNC milling machines feature a heavy-duty thickened bed welded with 200*300mm square tubes, side hanging structure, cast iron column and 150*200mm gantry frame. Equipped with CNC machining center to finish precision aviation aluminum head parts.
SESAME series CNC milling machine adopts reducer structure. Compared with the characteristics of loose gear box and synchronous belt, short life and no obvious deceleration effect, SESAME series CNC milling machine has the advantages of small backlash, low noise, high strength and accurate deceleration. Impact.
SESAME series CNC routers are assembled by the precision instruments of the professional assembly team of Youte, ensuring the accuracy of repeated positioning ±0.01mm and the accuracy of returning to the mechanical origin ±0.02mm.
SESAME series CNC routers use industrial-quality, high-precision linear guides to provide less rolling torque resistance and greater motor torque. And with dust cover, reduce friction, prolong service life.
Patent separable structure
The SESAME CNC's legs and body can be separated freely, saving packaging volume and shipping costs.
l If you are individual buyer: 2 sets /3 sets can be packed in wooden cases
l If you are a dealer
A 20'GP container that packs 6 sets of SESAME 1325.
One 40'HQ container can pack 14 sets of SESAME 1325.
Easy to install the disassembly method and installation guide video, so that you have no worries at home.
Patent separable structure
The SESAME CNC's legs and body can be separated freely, saving packaging volume and shipping costs.
l If you are individual buyer: 2 sets /3 sets can be packed in wooden cases
l If you are a dealer
A 20'GP container that packs 6 sets of SESAME 1325.
One 40'HQ container can pack 14 sets of SESAME 1325.
Easy to install the disassembly method and installation guide video, so that you have no worries at home.
Descriptions | Parameters | |||
Model | SESAME S2 1325 | SESAME S2 1530 | SESAME S2 2030 | SESAME S2 2040 |
Working area | 1300*2500mm | 1500*3000mm | 2000*3000mm | 2000*4000mm |
Accuracy | 0.05mm | |||
Table Surface | Vacuum&T-slot table | |||
Frame | Square pipe welding bed structure 200*300mm+150*200mmgantry | |||
X, Y Structure | 1.25M Gear and rack transmission, Taiwan Linear Rail | |||
Z Structure | Taiwan TBI Ball Screw, Taiwan Linear Rail | |||
Spindle Power | 4.5kw air cooled spindle+ER25 cutter | |||
Spindle Speed | 0-24000RPM | |||
Drive Motors | JMC stepper motor and driver | |||
Working Voltage | AC 220/380V | |||
Command Language | G Code | |||
Operating System | HD100 handle controller (DSP or Mach3 optional) | |||
Computer Interface | Ethernet (or USB) | |||
Inverter | Best | |||
Software | Vectric Aspire/Type 3 /Artcam /Ucancam/JDPaint |
Descriptions | Parameters | |||
Model | SESAME S2 1325 | SESAME S2 1530 | SESAME S2 2030 | SESAME S2 2040 |
Working area | 1300*2500mm | 1500*3000mm | 2000*3000mm | 2000*4000mm |
Accuracy | 0.05mm | |||
Table Surface | Vacuum&T-slot table | |||
Frame | Square pipe welding bed structure 200*300mm+150*200mmgantry | |||
X, Y Structure | 1.25M Gear and rack transmission, Taiwan Linear Rail | |||
Z Structure | Taiwan TBI Ball Screw, Taiwan Linear Rail | |||
Spindle Power | 4.5kw air cooled spindle+ER25 cutter | |||
Spindle Speed | 0-24000RPM | |||
Drive Motors | JMC stepper motor and driver | |||
Working Voltage | AC 220/380V | |||
Command Language | G Code | |||
Operating System | HD100 handle controller (DSP or Mach3 optional) | |||
Computer Interface | Ethernet (or USB) | |||
Inverter | Best | |||
Software | Vectric Aspire/Type 3 /Artcam /Ucancam/JDPaint |
l Signage and advertising (indoor and outdoor signage, carvings and bas-reliefs, 3D letters, funerals)
l Relief and 3D carving and cylinder projects.
l Plastics and composites (ACP, ACM, solid surface materials, etc.)
l Nonferrous metals and oceans
Applied materials
Wood: Plywood, cork, hardwood, MDF, Particleboard
Plastics: acrylic, ABS, HDPE, PVC, UHMW, HDPE
Stone: granite, marble, SLATE, basalt, cobblestone, natural stone, ceramics, porcelain
Soft metals: Aluminum, brass, copper, mild steel
Composite material: aluminum composite material, copper composite material, titanium composite material, zinc composite material.
l Signage and advertising (indoor and outdoor signage, carvings and bas-reliefs, 3D letters, funerals)
l Relief and 3D carving and cylinder projects.
l Plastics and composites (ACP, ACM, solid surface materials, etc.)
l Nonferrous metals and oceans
Applied materials
Wood: Plywood, cork, hardwood, MDF, Particleboard
Plastics: acrylic, ABS, HDPE, PVC, UHMW, HDPE
Stone: granite, marble, SLATE, basalt, cobblestone, natural stone, ceramics, porcelain
Soft metals: Aluminum, brass, copper, mild steel
Composite material: aluminum composite material, copper composite material, titanium composite material, zinc composite material.
Packing:
1/ If the machine is delivered via LCL, then would be packed with wrapping film, EPE foam, and a standard export plywood box.
2/ If the machine is delivered in FCL, wooden cases are not required and will be packed with packaging film and EPE foam.
Shipping:
We support machine delivery via express, air transportation, land transportation, and sea transportation.
1/ Such as some small machine, Mini CNC Router or Small CO2 Laser Machine and Fiber Laser Marking Machine, usually delivered via
express and air transportation.
2/ If you wanna us to help you deliver to a domestic warehouse or Russia, Kazakhstan, etc, usually delivered via land transportation.
3/ Large machines or some countries where shipping is more convenient, usually suggest choosing sea transportation.
You can choose any way you'd prefer, we also will give you some proper suggestions.
Packing:
1/ If the machine is delivered via LCL, then would be packed with wrapping film, EPE foam, and a standard export plywood box.
2/ If the machine is delivered in FCL, wooden cases are not required and will be packed with packaging film and EPE foam.
Shipping:
We support machine delivery via express, air transportation, land transportation, and sea transportation.
1/ Such as some small machine, Mini CNC Router or Small CO2 Laser Machine and Fiber Laser Marking Machine, usually delivered via
express and air transportation.
2/ If you wanna us to help you deliver to a domestic warehouse or Russia, Kazakhstan, etc, usually delivered via land transportation.
3/ Large machines or some countries where shipping is more convenient, usually suggest choosing sea transportation.
You can choose any way you'd prefer, we also will give you some proper suggestions.
