Sesame-P1
UTECH
UT-1325P
Factory price machine plasma 80 amp 25mm cutting plasma cutter machine
CNC Plasma Cutting Machine is automatic and high efficiency cutting equipment. CNC Plasma Cutting Machine is widely used in all kinds of carbon materials cutting, mild steel materials cutting and nonferrous metal precision sheet metal cutting.
Advantages:
Cutting faster, more accurate control, the cutting surface is more smooth, no glitches, no black; cutting holes in high quality.
Stability and reliability for light path system and control system.
Humanizing design, convenient operation.
High-performance price ratio, low operating cost >High cutting efficiency, and quality, no noisy. Small heat influence area, cutting seam smooth and no deformation, post-treatment is not needed.
The machine adopts Beijing START plasma control system, standard high sensitivity arc voltage device.
High precision stepper motor and driver, ensure the efficiency and accuracy, increasing the stability and reliability greatly.
Details:
| MACHINE PARAMTER | |
| Processing area | 1300*2500mm |
| Working thickness | 30mm |
| Z axis feeding height | 180mm |
| Working material | Iron, aluminum, titanium, stainless steel and others |
| Running speed | 0-15000mm/min |
| Cutting speed | 0-10000mm/min |
| Power | 10.5KW |
| Input voltage | 380V/220V/110V |
| Power supply frequency | 50HZ/60HZ |
| Plasma power supply | 100A |
| File transfer mode | USB interface |
| Working method | Non contact arc |
| Driving mode | Gear driving |
| Mode of motion | Gantry driving |
| X axis motor and drive | JMC Stepper motor and drive |
| Overall dimension | 2200*3300mm |
| Ventilation system install mouth | Double ventilation mouths |
| Weight | 1000kg |
| Cooling System | DSP A12S or STARFIRE |
| Guide rail | Taiwan PMI linear square rail |
| Plasma generator(power) | Huayuan or Hypertherm plasma(USA) |
| Plasma cutting gun | huayuan or Hypertherm plasma cutting gun |
| Floating cutting gun mode of motion | Automatic and Pneumatic test |
| System | Beijing Start controlling system |
| Floating adjustable block | Beijing Start Floating adjustable block |
| Body configuration | Steel |
| Table configuration | Steel table frame iron lattice |
| Material fixed mode | Electrode plate |
| processing cutting instruction | EMG, G-code, U00, MMG, NC |
| Machine positioning | ±0.15/300mm |
Parts:
Standard Configurations:
1) standard working area 1300*2500mm working area
2) Beijing STARFIRE control system 63A+ARF Height Controller(Automatic Rise and Fall)
3) JMC stepper motor&driver
4) Gear rack and square rail guide transmission
5) Sawtooth table
6) Heavy duty machine body with 5mm thick square tube
7) FASTCAM software
8) Instruction of STARFIRE control system and FASTCAM software.
9)Huayuan 120A plasma Power(Optional: Hypertherm power supply)
10)Cutting Material Collection Box with wheels, for easy take out products
1) Servo motor&driver(any brnad)
2) Huayuan 63A, 100A, 120A, 160A, 200A; Hypertherm 45A, 65A, 85A, 105A, 125A
3) Water tank/Water table
4) Flat table Etc.
Applicable Materials: Aluminum, Copper, Titanium, Nickel, Iron, Galvanized Sheet, White Steel, Titanium Plate, Carbon Steel, Stainless Steel, Alloy Steel, Composite Metal.
